Specifications:
Material And Finish:
Insulator:PA66 UL94V-0
Contact:Copper alloy
Plated:Silver Plated
Wire Specifications:10/16/25mm2
Insertion force:≤75N
Rating:
Current Rating:120 Amp
Operating Voltage:1000V DC
Operating Temperature Range:-40°~+125°C
Electrical:
Contact resistance:0.2m Ohm Max
Insulator resistance:500MΩ Min
Withstanding Voltage:3000V AC/Minute
Protection level: IP67/UL94 V-0 after mutual matching
Temperature rise:45℃ Max
