Specifications:
Material And Finish:
Dvi Housing:PBT,UL94V-0,Color: Black or White
Dvi Cover:LCP,UL94V-0,Color:Black or White.
Contact:Copper Alloy,Gold flash in contact area,
Tin plated in solder area,Nickel under plated over all
Shell: SPCC,Nickel plated over copper under plated over all
Board lock: SPCC, Tin plated over Nickel under plated over all.
Bracket: SPCC, Nickel plated over Copper under plated over all.
Semi Shield:Sus Non-plated
Rivet: Copper alloy, Nickel plated over Copper under plated over all
Crew: Steel, Nickel plated over Copper under plated over all
Rating:
Current Rating:1.5 Amp
Voltage Rating:250V AC/DC
Operating Temperature Range:-20°~+85°C
Electrical:
Contact resistance:Up port 30m Ohm Max
Lower port 20m Ohm Max
Insulator resistance:100M ohm min.at DC 500V
Withstanding Voltage:500V AC/Minute
Resistance to Soldering Heat: 265'C for 5s
Only applicable to wave soldering process
Mating force: 4.5kgf max
Unmating force: 1.0~4.0kgf
